Magnet used in toys

( HS Code : 8505119000 )

1. Meterial:Nd2Fe14B (Nd 32%、Fe64%、B1%, other 3% like Dy、Tb、Co、Go、Al、Cu)

Neodymium magnet

2. Technology: Utilizes new Sintered NdFeB magnet techniques and equipment such as strip

casting, HDDR technology

3. Magnetic properties:High coercive force, the max operation temp is up to 200 degree centigrade

or 380 curie temperature;

4. Grades:N35-N52, 33M-48M, 33H-48H, 30SH-45SH, 30UH-38UH and 30EH-35EH;

5. Shapes and sizes: Various kinds or according to customers' request .

6. Coatings: Ni, Zn, Phosphating, epoxy and so on;

7. Applications:  Widely used in different applications, such as sensors, motors, rotors, wind turbines,

wind generators, loudspeakers, magnetic hooks, magnetic holder, filters automobiles and so on.

8. Quality Control : Our QC team consists of more than 12 professional people to ensure 100%

products high quality .

9. Extremer Power Warming : These magnets are dangerous ! If your fingers are trapped between

two they will cut your skin.Please be note they should  only be handled with great care .

10. Transportation : 1Express:As magnet has magnetism,regarded as dangerous goods,to most of

the countries,it can only be safely delivery via DHL with dangerous goods method .2 If weight more than 200kg,

we suggest by air or by sea.

                                                                Magnetic Characteristics

Note:The operating temperature is tested under 20°±2°C, the inevitable  loss of magnetic force is no more than 5%

                                                              Magnetization Direction

                                                                                            Factory Corner

                                                                            SGS CERTIFICATE

                                                                                       Package

Scan it and contact us!

For further products,please find in our Alibaba.com platform : http://ytmagnet.en.alibaba.com
